Tripod Screen 70" (1:1)
Tripod Screen 70" (1:1) ฿2,097

Visualizer GL-845W

฿10,047

3D image transmitter The device has a distinctive design. It has complete buttons. It meets the needs of use, whether it is in the business, education, or other presentations that use documents, transparent objects, objects with 3D shapes, X-ray film sheets. It works in real time and can automatically adjust the sharpness.

Add Friend
Add to wishlist
Download PDF
  • 1 year warranty

Read More

  • Free returns within 7 days

Read More

SKU: VG-GL-845W Category: Visualizer Tags: Visualizer, วิชวล, วิชวลไลเซอร์, เครื่องฉายภาพ, เครื่องฉายภาพ 3 มิติ, Visualizer GYGAR GL-845W, VG-GL-845W, Visual
  • FacebookFacebook
  • XX
  • LINELine
  • Description & Feature
  • More Information
Description & Feature

Features

Visualizer GL-845W 5

Fast focus
Makes the details of the image complete. and is clear Throughout the presentation, even when zooming in and out to adjust the perspective, making every presentation smooth.

Visualizer GL-845W 6

Complete connectivity
Responds to all digital connections with peripherals both entering and exiting Make the connection easy and hassle-free.

Visualizer GL-845W 7

Every picture is sharp
There is less noise on the image, making the image displayed in bright colors, clear, realistic and more comfortable for the eyes. With CMOS sensor technology, every display is sharp and clear.

Visualizer GL-845W 8

Continuous display
With a capture rate of 45 frame rate, the display is smooth and continuous in every movement.



More Information
Optical system Lens F=1.4-2.6, f=3.9-85 mm
Shooting Area 297×210 mm
Zoom 22x Optical, 10x Digital
Focus Auto/manual
Exposure Auto/manual
Image system Image sensor CMOS 1/3″
Total pixels 8. Mega pixels
Horizontal Resolution 1100 TV Line
Frame rate 45 fps(max) XGA, 720P, 1080P
White Balance Auto/manual
VGA OUTPUT V: (60/75 ± 0.2)HZ
Video system TV system PAL PAL
Composite Video 1V±0.2 Vp-p 75Ω
Audio -10dB 10KΩ or more
Light system Side Arm Lamp 1W x2, LED
Base Lamp 1W x1, LED
Input Port) VGA IN D-SUB 15 Socket x1
Composite Video RCA Socket x1
Audio 3.5mm Stereo Socket x1
MIC Socket x1
RS-232 D-SUB 9 Socket x1
HDMI IN x1
Output Port) VGA OUT D-SUB 15 Socket x2
Composite Video RCA Socket x1
S-Video Mini DIN 4 jack x1
Audio 3.5mm Stereo Socket x1
USB 2.0×1
HDMI OUT x1
Image effect Color/B/W/Negative /Mirror/ Reverse/Freeze
Controlling method Control panel; remote/RS232
Operating conditions Power supply) DC 12V,2A
Power consumption ≤40W
Temperature 0 ℃~40℃
Machine size Unfolded 450x370x550 mm
Machine folding 482x370x130 mm
Conditions of use Weight 3.4 kg
Warranty 1 year
