| Brightness (Ansi Lumens) |
6,000 |
| Display panel |
3×0.64 with MLA |
| Display Technology |
Liquid Crystal Display |
| Native Resolution |
WXGA (1280 x 800) |
| Lifetime |
20,000hrs(Normal) / 30,000hrs(Eco) |
| Zoom/Focus Lens |
Manual |
| Throw Ratio |
1.2(wide)-2.1(Tele) |
| F |
F1.7~2.21 |
| f |
17.42~28.99mm |
| Zoom ratio |
1.66x |
| Screen size |
30-300 inch |
| Lens Vendor |
FUJIFILM |
| Dynamic Contrast Ratio (FOFO) |
5,000,000:1 |
| Native Contrast Ratio (FOFO) |
400:1(Min) |
| Noise (dB) |
37dB(Normal), 29dB(ECO1), 27dB(ECO2) |
| Uniformity (Actual Min) |
80% |
| Aspect Ratio |
Native:16:10/Compatible: 4:3/16:9 |
| VGA IN |
1 |
| HDMI |
2 |
| Audio in (mini jack,3.5mm) |
1 |
| USB-A |
1 |
| USB-B |
1 (Display) |
| RJ45 |
1 (Display) |
| VGA OUT |
1 |
| Audio out (mini-jack,3.5mm) |
1 |
| RS232 |
1 |
| RJ45 |
1 (Control) |
| Speaker |
16W*1 |
| Dust filter |
W/Filter |
| Filter Life time |
8000h |
| Power requirements |
100~240V@ 50/60Hz |
| Power Consumption (Normal) (Max) |
350 |
| Power Consumption (ECO1) (Max) |
240 |
| Power Consumption (ECO2) (Max) |
220 |
| ECO Standby Mode Power Consumption |
<0.5W |
| Operating Temp. |
0 to 40deg.C |
| Operating Thumidity. |
20-85% |
| Store Temp. |
-10 to 50deg.C |
| High altitude |
0-3000m |
| Keystone Correction |
V: ±30° |
| Keystone Correction (Lens@center) |
H: ±30° |
| LAN Control-RoomView (Crestron) |
Yes |
| LAN Control-AMX Discovery |
Yes |
| LAN Control-PJ Link |
Yes |
| WiFi |
Yes |
| H-Synch Rang |
15~100KHz |
| V-Synch Rangee |
24~85Hz |
| Computer Signal Input |
VGA, SVGA, XGA,SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Video Signal Input |
480i, 480p, 576i, 576p, 720p, 1080i and 1080p |
| MAX Dimensions (WxDxH mm) |
405x358x137 |
| Net. Weight (KG) |
7.7 KG. |
| Packaging Box Dimensions (WxDxH mm) |
510x498x260 |
| Gross. Weight (KG) |
~10.2KG. |
| Manual Languages |
Chinese, English |
| Standard Accessories |
Power cord Remote control&RC Battery |
| Picture mode |
Dynamic, Color board, sim-DICOM, Blackboard(green), Cinema, Standard |
